Many problems in scientific computing include:

  • Solving linear equations
  • Eigenvalue computations
  • Singular value decomposition
  • LU/Cholesky/QR decompositions
  • etc… And the userbase is quite large for this types of computation (number of scientists in the world is growing exponentially )

Quick History of Performance Computing

Early seventies it was EISPACK and LINPACK. Then In similar years Matlab was invented, which simplified a lot compared to previous systems. LAPACK redesigned the algorithms in previous libraries to have better block-based locality. BLAS are kernel functions for each computer, while LAPACK are the higher level functions build on top of BLAS (1, 2,3). Then another innovation was ATLAS, which automatically generates the code for BLAS for each architecture. This is called autotuning because it does a search of possible enumerations and chooses the fastest one. Now autotuning has been done a lot for NN systems.

  1. Vector sum
  2. Matrix vector product
  3. MMM (scales with the cache size, so this was the preferred version for speed).

On Strassen’s Algorithm

Indeed there are faster methods for matrix to matrix multiplication Yet, it is much less numerically stable and complex compared to the standard one, and it is not used in practice.

ATLAS Architecture

  1. Fixes some hyperparameters (bounds, possible choices. hardware parameters)
  2. Then it generates the code for each architecture.
  3. Tests it on the architecture
  4. Repeasts and chooses the best one. Fast Linear Algebra-20250324105542265

But this is not quite transparent, it does not tell you why it is the best. Others have built a Model-Based ATLAS that finds the parameters in theory for the code. It gives you some understanding.

An advantage is that this model is able to adapt to new architectures, and it is not limited to the ones that are already in the database (but we don’t know why it chooses that, so it is scientifically unsatisfactory).

Optimizing MMM

Loop Order

Consider a multiplication in the form $C = AB$. And a loop in the form:

for (i = 0; i < n; i++)
    for (j = 0; j < n; j++)
        for (k = 0; k < n; k++)
            C[i][j] += A[i][k] * B[k][j];

Then it is better to have:

  • i-j-k if B is smaller than A (B is re-used).
  • j-i-k if A is smaller than B (A is re-used).

Blocking for Cache

This is called micro-MMM. Blocking is used to improve the cache locality. It uses mini matrix matrix multipications. ATLAS uses this count for the cache size: $N_{B}^{2} \leq \min(C, 80^{2})$. The idea is that the working set should fit into memory.

The classical model is $3N_{B}^{2} \leq C_{1}$ but closer analysis can highlight the following:

  • $B$ is reused
  • $A$ is used only once. $$ \underbrace{N_{B}^{2}}_{\text{all of } b} + \underbrace{N_{B}}_{\text{row of }a} + \underbrace{1}_{\text{ element of } c} \leq C_{1} $$ It might also be useful to take block size into measure: $$ \left\lceil \frac{N_{B}^{2}}{B_{1}} \right\rceil + \left\lceil \frac{N_{B}}{B_{2}} \right\rceil + 1 \leq \frac{C_{1}}{B_{1}} $$

We would like to evict the row of $A$, and always keep the matrix $B$ in cache. But it is not possible in practice to make this fit perfectly, cache eviction is not software controlled. In reality, we need to fit at least two rows of $A$. In the model we might need to fit a little bit more.

Blocking for Registers

This is called micro-MMM This is the reason why ATLAS prefers the second version, better instruction level parallelism.

Fast Linear Algebra-20250324113716991

So the optimized version should take this into account, and when it still fits into memory, you should do the outer loop.

Types of dependencies

Fast Linear Algebra-20250324114924896 In hardware, it might be that every logica register has many physical registers under it. Some renaming is done at the hardware level (aliased). - CPU can do the renaming on the fly (this was relevant for the matric multiplication analysis).

Micro-MMM model

$$ M_{U} \cdot N_{U} + N_{U} + M_{U} \leq Reg $$

The number of registers, which is 16 usually. (In the paper, the count of the registers is a little more complex).

Read after write mechanisms in real ATLAS code, but the hardware renaming solved it.

  • For b we only use a single register, one for a and 14 for C.

Virtual Address Performance Incluences

Cache lookup can start in parallel with the address translation (faster access to level 1 and 2 caches). Exactly the last 6 bits match with the row for the cache lookup. Cannot change page size -> cache line size is fixed, you can only extend memory of cache with associativity. Uses TLBs (See Paginazione e segmentazione) to know what physical page is associated to the virtual page. For skylake:

  • 128 entries for instructions (which is a lot for instruction pages)
  • 64 entries for data: few cycles of penalty
  • STLB miss with 1536 entries, is very very expensive (as long as the data is in this cache, then it is ok, about 6MB it seems), but it fits in the L2 cache (slowdown for address translation).

Evil Patterns

If you repeatedly access more pages than the TLB can handle, then it would be much slower (see working set in Memoria virtuale). We just needs jumps larger than the page size, like 4kb. For example, in matrix matrix multiplication, we have M jumps for AB=C, matrix B, and this could make you load many many pages.

  • A contiguous, B is contiguous working set, C has $N_{B}$ pages if $M$ is too big.

But if we consider the BLAS MMM multiplication, then the answer could be a little different, It could be that $B$ matrix is spread over too many matrices.
